We are a factory specialized in metal parts hardware & metal gearbox geared motor through powder metallurgy process .We services with ODM/OEM gearbox design and development , gearmotors manufacture. Custom planetary gears .

A planetary gearbox is a gearbox with the input shaft and output shaft aligned it offers high torque transmission with good stiffness and low noise , in a more compact foot print than other gearbox types . It can supply a lot of speed reduction and torque in a small package with the fixed axis .

Gearbox is ensure that it provides highly accurate gear engagement, smooth running and minimum noise and give the ability to increase the torque and lower the speed of an electric motor.

Since the torque transmitted by the sun gear is equally distributed among planetary gears (3-5 gears), the load applied to each gear is small, realizing a compact and lightweight planetary gear reducer. The 5-gear planetary system is made possible due to our original carrier.

Description: Product Name : 16mm low speed high torque geared motor / Speed reducer / steel gearbox,powder transmission gear ,speed reducer Gearbox Type: Planetary Material: Steel Gear backlash: ≤2° Bearing:Porous Bearing ,Rolling bearing Radial loading on output shaft:≤ 30 N Gear Ratio : 5:1 , 10:1 , 20:1 , 25:1 , 30:1 , 40:1 , 50:1 , 60:1 ,70:1…100:1...

optional Gearbox diameter : 8mm , 12mm , 16mm , 22mm , 24mm ,28mm, 32mm ,36mm, 38mm , 42mm , 48mm ...... 3V , 6V ,12V ,24V available . High Torque Brushed/Brushless/Stepper/AC Motor Usage Planetary Gearbox/Gear Reducer. Planetary Gearbox advantages: Provides high torque at slow speeds .

The shafts are made up of hardened and tempered alloy steel . Sun gears ,planet gears and ring gears are made of powder metallurgy and sintering steel . Low noise levels. Good quality taper roller bearings for input and output shafts . High efficiency . Increased repeatability .

Its Its greater speed radial and axial load offers reliability and robustness, minimizing the misalignment of the gear. In addition, uniform transmission and low vibrations at different loads provide a perfect repeatability.

Perfect precision: Most rotating angular stability improves the accuracy and reliability of the movement. Lower noise level because there is more surface . Rolling is much softer and jumps are virtually nonexistent. Greater durability: Due to its torsional rigidity and better rolling.

To improve this feature, your bearings help reduce the losses that would occur by rubbing the shaft on the box directly. Thus, greater efficiency of the gear and a much smoother operation is achieved. Increased torque transmission: With more teeth in , the mechanism is able to transmit and withstand more torque.

In addition, it does it in a more uniform manner. Very good levels of efficiency: Planetary reducers offer greater efficiency and thanks to its design and internal layout losses are minimized during their work. In fact, today, this type of drive mechanisms are those that offer greater efficiency.

Maximum versatility: Its mechanism is contained in a cylindrical gearbox, which can be installed in almost any space.

Application: monitor,automatic vending machine,automatic cruise control,door lock actuator, retractable rearview mirror, meters, optic axis control device, head light beam level adjuster,printers,conditioning damper actuator,Car tail gate electric putter,tooth brush,vibrator, sanitary ware,coffee machine,Sweeping robot,toys etc.

Custom geared motors , planet gears , metal gearbox Welcome OEM ODM projects . Encoder available Workshop
